Features for the SN65HVDA541-Q1

• Qualified for Automotive Applications
• AEC-Q100 Qualified With the Following Results:
  • Device Temperature Grade 1: –40°C to 125°C
  • Device HBM ESD Classification Level 3A
  • Device CDM ESD Classification Level C6
  • Device MM ESD Classification Level M4
• Meets or Exceeds the Requirements of ISO 11898-2 and ISO 11898-5
• GIFT/ICT Compliant
• ESD Protection up to ±12 kV (Human-Body Model) on Bus Pins
• I/O Voltage Level Adapting
  • SN65HVDA54x: Adaptable I/O Voltage Range (VIO) From 3 V to 5.33 V
  • SN65HVDA54x-5: 5 V VCC Device Version
• Operating Modes:
  • Normal Mode: All Devices
  • Low Power Standby Mode (VCC Not Required, Only VIO Supply Needed Saving System Power)
    • SN65HVDA540: No Wake Up
    • SN65HVDA541: RXD Wake Up Request
  • Silent (Receive Only) Mode: HVDA542
• High Electromagnetic Compliance (EMC)
• Protection
  • Undervoltage Protection on VIO and VCC
  • Bus-Fault Protection of –27 V to 40 V
  • TXD Dominant State Time Out
  • RXD Wake Up Request Lock Out on CAN Bus Stuck Dominant Fault (HVDA541)
  • Thermal Shutdown Protection
  • Power-Up/Down Glitch-Free Bus I/O
  • High Bus Input Impedance When Unpowered (No Bus Load)

Description for the SN65HVDA541-Q1

The SN65HVDA54x-Q1 and SN65HVDA54x-5-Q1 devices, known as the HVDA54x and HVDA54x-5 respectively, are designed and qualified for use in automotive applications and meets or exceeds the specifications of the ISO 11898 High Speed CAN (Controller Area Network) Physical Layer standard (transceiver).
